Features2MP ( 1920 x 1080 ) H.265 full real time coding Max. resolution: 1920 x 1080; ICR auto switch, true day / night 30~ 50m IR night view distance Starlight 3D DNR, Digital WDR, HLC, BLC and Defog ROI coding Built-in micro SD card slot, up to 128GB DC12V/PoE power supply IP67 ingress protection; Support dual streams Support mobile surveillance by smart phones with iOS and Android OS Intelligent Analytics: video blur detection, line crossing detection, intrusion detection*Δεν περιλαμβάνει τροφοδοτικό ** Η απομακρυσμένη πρόσβαση στην κάμερα είναι δυνατή μόνο μέσω καταγραφικού. Διαφορετικά είναι εφικτή μόνο μέσα από το ίδιο δίκτυο. CameraImage Sensor1 / 2.8 “CMOSImage Size1920 ? 1080Electronic Shutter1 s ~ 1 / 100000 sIris TypeFixed IrisMin. Illumination0.007 lux@F2.0,AGC ON; 0 lux with IR 0.0028 lux@F1.2,AGC ON; 0 lux with IRLens2.8 mm @F2.0, H.FoV: 103.5°; V.FoV:54.1°; D.FoV:107.7Lens MountM12 or O14 optionalWide Dynamic RangeDigital WDRBLCYesHLCYesDefogYesDigital NR3D DNRAngle AdjustmentPan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360°ImageVideo CompressionMain stream: H.265 / H.264; Sub stream: H.265 / H.264 / MJPEGH.264 Compression StandardBaseline Profile/Main Profile/High ProfileResolution1080P ( 1920 ? 1080 ), 720P ( 1280 ? 720 ), D1, CIF, 480 ? 240Main Stream60Hz : 1080P( 1 ~ 30fps ) / 720P( 1 ~ 30fps )50Hz : 1080P( 1 ~ 25fps ) / 720P( 1 ~ 25fps )Sub Stream60Hz : D1/CIF/480×240 (1~30fps); 50HZ: D1/CIF/480×240 (1~25fps)Bit Rate128 Kbps ~ 6 MbpsBit Rate TypeVBR / CBRAudio CompressionG711A / UImage SettingsROI, Saturation, Brightness, Hue, Contrast,Wide Dynamic, Sharpness, NR, etc. adjustable through client software or web browserROIEach ROI to be configured separatelyInterfacesNetworkRJ 45Video OutputNOAudio1CH audio inputStorageBuilt-in micro SD card slot, up to 128GBResetYesFunctionsRemote MonitoringWeb browsing, CMS remote controlOnline ConnectionSupport simultaneous monitoring for up to 3 users; Support multi-stream real time transmissionNetwork ProtocolUDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, 802.1x, SMTP, FTP, UPnP, HTTPs, HTTP, QoSInterface ProtocolONVIFStorageNetwork remote storage; micro SD card storageIntelligent AnalyticsVideo blur detection, intrusion detection and line crossing detectionSmart AlarmMotion detection, SD card error, SD card fullGeneral functionWatermark, IP address filtering, video mask, heartbeat, illegal loginlockPoEYesIR Distance30~ 50 mIngress ProtectionIP 67OthersPower SupplyDC12V/PoEPower Consumption 7WOperating Environment- 30 °C ~ 60 °C (-22°F~140°F)Humidity: less than 95 % (non-condensing)Dimensions ( mm )217.7 x 80.5 x 80.5Weight ( net )Approx. 0.64KGInstallationCeiling mounting; wall mountingCertificateCE, FCCEnvironmental ProtectionComplies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
