● Up to 30W Power Supply● Supports 10/100/1000 Base-T applications● LED indicators power input and PoE output● Internal AC/DC converter no need for external power brick● Easy plug-and-play installation● Muti-protection● Compatible with PoE 802.3af and PoE+ 802.3at DevicesModelPOE200No. of channels1Pass Through Data Ratesi10/100/1000MbpsPower over Ethernet OutputPin Assignment and Polarity: 1/2 (-), 3/6 (+)Output Power Voltage: 54VDCUser Port Power: 30W maxInput Power RequirementsAC Input Voltage: 100 to 240 VACAC Input Current: 0.5A 100-240 VACAC Frequency: 50 to 60 HzDimensions121mm x 50mm x 36mmIndicatorsSystem Indicator: AC PowerUser Indicator: Channel PowerConnectorsShielded RJ-45, EIA 568A and 568BProtectionOver current protectionOver load protectionOver voltage protectionAnti-interference protectionEnvironmental ConditionsOperating Ambient Temperature:-40 to 40℃Operating Humidity: Maximum 85%, Non-condensingStorage Temperature:-40 to 50℃Storage Humidity: Maximum 90%, Non-condensing
35.53
