● Share 4G connection with up to 150/50 Mbps (download/upload)● Support FDD and TDD bands● Supports up to 10 devices simultaneously● 2000 mAh battery for 7 hours of usage
Model4G LTE Mobile Wi-FiDimensions97 x 61 x 15.5mmWeight92gFormMiFi / Pocket RouterCommunication System (WAN)ChipsetQualcomm MDM9x07 / MDM9x25Frequency BandsLTEB1/B3/B7/B8/B20/B38/B40/B41UMTSB1/B3/B8BandwidthLTE Band1.4/3/5/10/15/20 MHzModulationDownlinkQPSK/16-QAM/64-QAMUplinkQPSK/16-QAMAntennaPrimaryInternalDiversityInternal, UMTS OptionalRF Power LevelLTE FDDPower Class 3 (23 +/-2dBm)UMTSPower Class 3 (24 +1.7/-3.7dBm)Data Rate4G3GPP R10, Cat. 4, Downlink/Uplink up to 150Mbps/50Mbps3G3GPP R7 Downlink/Uplink up to 42Mbps/5.76MbpsWLANWi-FiChipsetRealtek 8192ESFrequency2.4GHzProtocol802.11b/g/nChannel1~13AntennaInternalData Rate802.11bUp to 11 Mbps802.11gUp to 54 Mbps802.11nUp to 150 MbpsFeatureInterfaceUSBUSB2.0USIMSingle, 4FFLEDPOWERPower/Battery Status IndicatorNetwork4G/3G/2G Network Status IndicatorWi-FiWi-Fi Status IndicatorWebUISystemConnection StatusStatisticsSamba (optional)Device ManagementPower MangementMobile ServiceAutomatic APN matching according to USIMAuto Data ConnectionPIN/PUK ManagementNetwork Mode Selection(2G/3G/LTE/Auto)RouterUSB RNDIS DeviceUp to 10 Wi-Fi users/devicesDHCP ServerIPv4/v6VPN PassthroughFirewallWPSSecurity via WEP, WPA-PSK, WPA2-PSKWi-Fi SettingsBatteryTypeLi-ion Polymer BatteryCapacity2000mAhEndurance7 hours (normal network situation)Operation SystemWindowsXP/7/8/10MAC OS10.7+LinuxUbuntu 13.04+BrowserIE9+, Firefox, Google Chrome, Safari, OperaEnvironmentPower SupplyUSB, 5V1AWorking Temperature0°C to 35°CStorage Temperature-20°C to 60°CCertification3GPP ComplianceCE/FCC/GCF, upon customers requirementMeterialRoHS
