● 5× 100/1000/2500 Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX ● IEEE 802.3x flow control and 4 Mbit packet buffer prevents packet loss● Power saving strategy saves power consumption when ports are idle● IGMP for high-efficienct multi-cast transmitting● Loop detection blocks loop automatically, improving reliability● Desktop and wall-mounting
ModelHS105Standard configurati5× 100/1000/2500 Mbps RJ-45 Ethernet PortsSwitching Capacity25 GbpsThroughput18.6 MppsPacket Buffer4 MbitMAC Address8KJumbo Frame15 KBTransfer ModeStore and forwardMTBF100000 hourNetwork protocolIEEE802.3u (100Base-TX)IEEE802.3ab (1000Base-T)IEEE802.3bz (2.5GBase-T)IEEE802.3x (Flow control)Network Medium100Base-TX : Cat5 or higher (≤100m)1000Base-TX : Cat5 or higher (≤100m)2.5GBASE-T: Cat 5e (≤50m), Cat 6 or higher (≤100m)Working EnvironmentWorking Temperature：-0~40°CStorage Temperature：-40~70°CWorking Humidity ：0%~100%, non-condensingStorage Temperature：5%~90%, non-condensingStructure SizeProduct Size：119×85×28 mm (4.69×3.35×1.1 inches)InstallationDesktop, Wall-MountingPower Saving Saves power consumption when ports are idlePower VoltageAdpter Input Voltage ：AC 100-240 V Switch Input Voltage:：DC 12V 1APower ConsumptionMax: 10.5WIdle: 4.7WESD Protection±4KV contact discharge and ±8KV air dischargeGrounding PointGrounding PointPackage Content SwitchPower AdapterQuick Installation GuideMounting Kit
